MED series is specially designed for the oil mist capture and purification of oily cutting fluid of CNC machine tools, electrostatic filtering, integrated body, low noise and low vibration. It is suitable for capturing and filtering of oily fumes in processing of various large, medium and small oily cutting fluids.
MED double electrostatic field oil mist purifier
MED series is specially designed for the oil mist capture and purification of high-end CNC numerical control machining machine oily cutting fluid, dual-stage electrostatic filter, integrated body, low noise, low vibration and no consumables. It is suitable for capturing and filtering of oily fumes in processing of various large, medium and small oily cutting fluids.
Product recommendation
new
one
· Product principle ·
The electrostatic main filter unit is generally divided into a dual ionization section and a collection end. The ionization section uses the most advanced ultra-high voltage power supply (6kv ~ 12kv) in China to generate high-voltage static electricity. Under the action of a high-voltage plasma electric field, tiny oil particles and gas are ionized. Charged, charged tiny ions (oil particles) enter the following collection section with the wind. Due to the potential difference between the plates in the collection section, the positive and negative phase suction advection technology is used to adsorb the charged ions on the plates and gradually The oil droplets are formed to settle in the oil collecting tank, thereby realizing the degradation, purification, and discharge of the oil mist particles and organic substances in the oil smoke oil mist exhaust gas.
two
· Product Features ·
1. High-efficiency EC fan or centrifugal fan (configured according to air volume requirements), efficient and stable performance, maintenance-free
2. In terms of high-voltage power supply, Puhua independently designed circuit control, double closed-loop control of current and voltage, and constant current and constant voltage output effectively prevent arcing and ensure constant purification efficiency
3. With short circuit, over current, under voltage, and overload protection; intelligent control arc (instantaneous or continuous arc) protection automatically cuts off the high voltage output and outputs a fault signal, which can achieve remote control and completely solve potential safety hazards
4. The safety protection design has a non-contact proximity switch. This device is equipped with a separate safety switch, that is, the electric field is turned on and the machine is automatically powered off.
5. Fundamentally guarantee the safety of operators and other safety accidents
6. In the control system, the inverter is used for startup and operation, and the standard configuration speed control panel can adjust the air volume of the oil mist purifier according to the size of the internal space of the CNC processing machine, so as to achieve the purpose of good ventilation effect and high filtering accuracy .
7. Electrical configuration: remote and local control switching, main power switch, power indication, running indication, fault alarm indicator.
Three
· Filtration level ·
Filter system adopts mechanical plate and frame filter + electrostatic field main filter combined structure
The first stage uses a metal plate-and-frame filter for equalizing and blocking large particles
Second stage, using multi-fiber metal filter to intercept small metal particles
The third level uses a labyrinth metal filter to intercept large particles of oil mist
The fourth level, using electrostatic filters, no consumables, low maintenance costs
Fifth stage, metal filter, purification and current sharing
Sixth stage, adopt electrostatic filter, second stage static, high efficiency filtering
Seventh stage, optional activated carbon filter to remove odor components
