The filter system is a combination of wet and dry methods. Wet filtration uses water filtration at running cost. Special exhaust dust can be added with specific agents (such as acid and alkali neutralization, and specific deodorants, etc.). When the smoke passes through the lower tank, the molecules and particulate pollutants collide with the mist droplets, and the droplets merge. Due to the larger surface viscosity of the oil molecules and particulate pollutants, they will be melted by the droplets. As the volume increases, sedimentation occurs, so that the particles in the particles are trapped by water, and the micron-level flue gas enters the lower-level processing area. Because a small amount of water mist brought out by negative pressure has a greater impact on the next processing process, the treatment of water mist is also critical. Here, a combination of the first domestic traditional packing ball defogging and an improved high-temperature and corrosion-resistant gas-liquid separator is adopted. This gas-liquid separator adopts a circular design. In the layer and gas-liquid separator, water molecules and particles in the flue gas will cause turbulent collision due to inertia and centrifugal force. The water molecules and particles will be trapped after colliding on the channel wall, and the smoke will pass through the fine The steel wire is beaten out, and the processed flue gas becomes a low-humidity gas and enters the lower-level dry filter system.

1. Wet and dry combination, specially designed for difficult to handle dust such as high temperature, oiliness, viscosity, odor or flammable and explosive dust.

2. Integrated design of filtering system and fan system, small footprint, easy to move.

3. A water mist isolator is designed between the dry filter and the wet filter to ensure that the water mist does not affect the service life of the dry filter.

4. The dry filtration is a multi-stage filtration structure. Coarse, medium, high efficiency and activated carbon filtration can be selected according to the properties of soot to ensure high filtration efficiency.

5. Quick-release filter cartridge filter structure, easy to clean and maintain.

6. The wet filter structure uses the principle of vortex + surface water film adsorption, and the patented structural design highlights the significant role of pre-filtration.

7, can be installed according to the requirements of the installation of automatic water system.

8. Cleaners, thinners, medicine barrels, etc. can be installed according to working conditions.

1.Laser marking of oily dust such as corrugated paper and label paper

2.Oil, viscous, high temperature, flammable and explosive dust and dust management
